M23 8 Pin Male Power Connector with 4-hole Flange, Panel Mount, Right Angle
Main Specifications:
| Product Number: | M23-08-P-2-R-H | |
| Connector Series: | M23 Panel Receptacle | |
| Connector Gender: | Male | |
| Orientation: | Right Angle | |
| Connector Coding: | A Coded | |
| Number of Contacts: | 8 Pin | |
| Contact Termination: | Solder | |
| Mount Method: | Panel Mount | |
| Mount Feature: | 4 Hole Flange | |
| Locking Type: | M23 x 1.0 | |
| Shielding: | Unshielded | |
| Rated Voltage: | 150V | |
| Rated Current: | 8A | |
| Insulation Resistance: | ≥1000 MΩ | |
| Contact Resistance: | ＜3 MΩ | |
| Coupling Method: | Threaded Coupling | |
| Operating Temperature: | -25°C to 85°C | |
| IP Rating: | IP67 | |
| Weight: | 92g |
Applications of this M23 8 Pin Male Power Connector:
M23 circular connectors are widely used in various industries due to their reliability, durability, and efficiency. Here are some applications:
- Industrial Automation: Connecting sensors, actuators, and control devices on the factory floor.
- Robotics: Establishing secure connections between motors, encoders, and control systems.
- Machinery: Facilitating the interconnection of various electrical and electronic components, ensuring efficient and safe operation.
- Transportation: Connecting electronic systems in transportation systems, such as railway and automotive.
- Renewable Energy: Providing durable connections for solar panels, wind turbines, and other sustainable energy systems.
- Medical Equipment: Connecting devices, sensors, and diagnostic instruments in healthcare settings.
- Process Control: Connecting instruments, controllers, and other devices in manufacturing and industrial processes.
- Test and Measurement: Connecting test and measurement equipment for data acquisition, instrumentation, and signal transmission.
- Aerospace and Defense: Providing rugged connections for avionics, communication systems, and military equipment.
- Data Communication: Connecting networking, telecommunications, and data transfer applications.
