Introduction:
Creating custom patch cords for gigabit networks is straightforward with this Cat5e RJ45 modular plug. It is designed to terminate 23-24 AWG round stranded cables used in standard Ethernet setups. Because it adheres to Cat5e specifications, the connector supports data speeds up to 1000 Mbps for efficient local area connections. The unshielded design offers a lightweight and cost-effective solution for indoor cabling environments. Its clear polycarbonate housing allows installers to observe the phosphor bronze contacts during the assembly process. This 8P8C component ensures a stable electrical bond and maintains high insulation resistance. Technicians rely on this plug for building durable networking links in residential or commercial systems.
Key Features
- Cat5e Speed Performance: Supports data transmission up to 1000 Mbps.
- 8P8C Modular Configuration: Provides standard connectivity for various network interfaces.
- 23-24AWG Compatibility: Accommodates specific copper wire gauges for termination.
- Round Stranded Support: Ensures secure fit for cylindrical cable profiles.
- Clear Polycarbonate Shell: Facilitates easy visual inspection of internal wiring.
Main Specifications:
General Information:
| Product No.: | MTPR-88-X-EMI | |
| Series: | MTP | |
| Category: | Modular Plugs | |
| Product Type: | RJ45 Plug | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1 Port | |
| Mounting Orientation: | Vertical | |
| Mounting Type: | Cable Mount | |
| Shielding: | Unshielded | |
| Performance Category: | Cat5e | |
| Wire Type: | Stranded | |
| Cable Type: | Round | |
| Wire range: | N/A | |
| OD of the Individual Cable Core: | N/A | |
| Body Length: | 22.4 mm |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150 V/AC | |
| Contact Resistance: | 20 mohms max | |
| Insulation Resistance: | 1000 Mohms min | |
| Dielectric withstanding voltage: | 1000 VDC or AC Peak for 1 minute |
Materials and Plating:
| Insulator Material: | Polycarbonate | |
| Insulator Color: | Clear | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Brass |
Environmental:
| Operating Temperature: | -25℃ to +55℃ | |
| Flammability Rating: | UL 94 V-0 |
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
