Introduction:
This 8p8c RJ45 male connector provides a reliable termination solution for voice-grade telecommunication systems. It is specifically designed to accommodate 24-26AWG solid round cables used in standard telephone and low-speed networking setups. Because it holds a Cat3 rating, the plug ensures stable signal transmission for various modular interfaces. The clear polycarbonate housing allows technicians to observe the internal phosphor bronze contacts easily during assembly. With a 1.5A current rating and 1000 Mohms insulation resistance, this connector maintains excellent electrical integrity. Professionals utilize this modular component for its straightforward cable mount installation in residential and commercial environments.
Key Features
-
8P8C Configuration: Supports standard modular connectivity for networking hardware.
-
24-26AWG Compatibility: Specifically designed for solid round copper wires.
-
Cat3 Rating: Meets performance requirements for reliable voice-grade links.
-
Polycarbonate Shell: Features clear housing for easy internal wire alignment.
-
Gold Plated Contacts: Phosphor bronze pins provide superior electrical conductivity.
Main Specifications:
General Information:
| Product No.: | MTPR-88-X-S | |
| Series: | MTP | |
| Category: | Modular Plugs | |
| Product Type: | RJ45 Plug | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1 Port | |
| Mounting Orientation: | Vertical | |
| Mounting Type: | Cable Mount | |
| Shielding: | Unshielded | |
| Performance Category: | Cat3 | |
| Wire Type: | Solid | |
| Cable Type: | Round | |
| Wire range: | 24-26AWG | |
| OD of the Individual Cable Core: | 0.89~0.99mm | |
| Body Length: | 22.4 mm |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150 V/AC | |
| Contact Resistance: | 20 mohms max | |
| Insulation Resistance: | 1000 Mohms min | |
| Dielectric withstanding voltage: | 1000 VDC or AC Peak for 1 minute |
Materials and Plating:
| Insulator Material: | Polycarbonate | |
| Insulator Color: | Clear | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -25℃ to +55℃ | |
| Flammability Rating: | UL 94 V-0 |
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
