BNC to SMA Straight Adapter, 50 Ohm, DC-18 GHz

Metabee Antenna Certificate
Get Quotation Chat Online

BNC to SMA Straight Adapter, 50 Ohm, DC-18 GHz

Introduction

This BNC to SMA adapter provides a reliable and precise 50 Ohm RF connection path for converting between BNC and SMA interfaces. Engineered for demanding applications, it maintains excellent signal integrity across an ultra-wide frequency range from DC to 18 GHz, making it ideal for test equipment, communication systems, radar, and high-frequency signal routing. The straight design ensures straightforward installation in confined spaces.

Constructed for durability and performance, both the BNC connector and SMA connector feature rugged stainless steel bodies with passivation plating for enhanced corrosion resistance. The adapter boasts an exceptionally low VSWR of 1.15:1, minimizing signal reflections and power loss for accurate measurements and transmission. It operates reliably in extreme environments, with a temperature range of -55°C to +165°C.

Key features:

  • Precise Impedance: 50 Ohm for minimal signal reflection.
  • Wide Bandwidth: Supports frequencies from DC to 18 GHz.
  • Low VSWR: Excellent 1.15:1 ratio ensures signal integrity.
  • Robust Construction: Stainless steel bodies for both connectors.
  • Corrosion Resistant: Passivation plating on all metal surfaces.
  • Straight Configuration: Simple, space-efficient connection.
  • Extended Temp Range: Operates from -55°C to +165°C.

Main Specifications:

Product No:  YC-BNC/SMA-JJS, YC-BNC/SMA-JKS, YC-BNC/SMA-KJS, YC-BNC/SMA-KKS
Product Series: SMA Adapters
Adapter Type: BNC to SMA
Brand: Metabee
Orientation: Straight
Connector 1 BNCConnector
Connector 1 – Body Material: Stainless Steel
Connector 1 – Body Plating:  Passivation
Connector 2: SMA Connector
Connector 2 – Body Material: Stainless Steel
Connector 2 – Body Material: Passivation
Mount Method: Not Applicable
Impedance: 50 Ohm
VSWR:  1.15:1
Frequency Range: DC-18 GHz
Operating Temerature:  -55 ºC to +165 ºC
Other Feature: None


Applications of this BNC to SMA Straight Adapter, 50 Ohm:

SMA adapters are incredibly versatile and widely used in the RF and microwave industry. They are a semi-precision coaxial connector, known for their compact size, excellent performance up to 18 GHz, and robust threaded coupling mechanism.

Here are some applications:

  • General RF and Microwave Connections;
  • Wireless Communication Systems;
  • Test and Measurement Equipment;
  • Radar Systems;
  • Satellite Communications;
  • Radio Amateur;
  • Automotive Electronics.

We can customize this RF Adapter according to your special requirements. Get a free quotation now!

RF Adapters
Metabee is a professional electronic component manufacturer from China. We can provide all kinds of RF Adapters.
Product Series

SMA Adapters

Product No.

YC-BNC/SMA-JJS, YC-BNC/SMA-JKS, YC-BNC/SMA-KJS, YC-BNC/SMA-KKS

Adapter Type

BNC to SMA

Product Name

BNC to SMA Straight Adapter, 50 Ohm, DC-18 GHz

Brand

Metabee

Orientation

Straight

Connector 1

BNC Connector

Connector 1 - Body Material

Stainless Steel

Connector 1 - Body Plating

Passivation

Connector 2

SMA Connector

Connector 2 - Body Material

Stainless Steel

Connector 2 - Body Plating

Passivation

Mount Method

Not Applicable

Impendence

50 Ohm

Frequency Range

DC-18 Ghz

VSWR

≤ 1.15:1

Operating Temerature

-55 ºC to +165 ºC

Other Features

None
