6P4C Unshielded RJ11 PCB Jack, 1 Port, Through Hole, Right Angle, Tab-Down, No LED
Introduction:
This is a single port 6p4c unshielded RJ11 PCB jack designed for stable right angle through hole attachment to circuit boards. It features a durable PBT housing available in either Pantone P362C Green or Cool Gray 3U color options to help technicians distinguish between different signal ports during hardware assembly. The premium Phosphor Bronze contacts include a Gold finish to ensure superior conductivity and a consistent 1.5A current rating. Utilizing a Tab-Down configuration, this component optimizes vertical clearance while maintaining high insulation resistance of 1000 mohms. Technicians utilize this reliable modular socket for standard telephone systems and networking gear requiring stable 4-pin connectivity across a -40°C to +85°C range.
Key Features
- 6P4C RJ11 Interface: Supports standard modular connectivity for voice networking systems.
- Diverse Color Options: Available in Pantone Green or Gray for easy identification.
- Gold Plated Contacts: Delivers superior conductivity and lasting signal stability.
- High Insulation Resistance: Maintains 1000 mohms for enhanced electrical safety.
- Right Angle Layout: Optimizes vertical space for specialized board layouts.
Main Specifications:
General Information:
| Product No.: | MTJ-640X2-N-P362C, MTJ-640X2-N-PC3U | |
| Series: | MTJ | |
| Category: | Single Port RJ11 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 6P4C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Latch Direction: | Tab-Down | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 125V AC | |
| Contact Resistance: | 20mΩ Max / 45mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Pantone Cool Gray 3U / Pantone P362C Green | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | 40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
