6-Port SFP Cage, 1×6 Ganged, Through-Hole, Stainless Steel Spring
Introduction:
This 1×6 ganged 6-port SFP cage accommodates six individual pluggable optical or electrical transceivers in a single row along the host interface. Constructed from durable copper alloy, the housing provides strong mechanical protection and dependable ground continuity across all ports. Integrated stainless steel EMI springs establish high-tension grounding contact against chassis bezel openings, suppressing high-frequency electromagnetic noise. Through-hole solder pins anchor directly into the PCB, giving the assembly superior resistance against torque and module insertion forces. Operating stably from -40°C to +85°C, this high-density cage supports core telecom switches, aggregation routers, and fiber distribution frames.
Key Features
-
1×6 Ganged Layout: Delivers dense six-transceiver capacity in one row.
-
Stainless Steel Springs: Maintains high-tension EMI grounding at panel seams.
-
Through-Hole Solder Mounting: Ensures rigid mechanical retention across the PCB.
-
Copper Alloy Structure: Provides low ground impedance and structural stability.
-
Industrial Temperature Range: Operates continuously between -40°C and +85°C.
Main Specifications:
General Information:
| Product No.: | SFC-6 | |
| Product Type: | Cage | |
| Pluggable Form Factor: | SFP | |
| Port Configuration: | 6 Ports (1×6 Ganged) | |
| PCB Mounting Style: | Through-Hole Solder | |
| Included Lightpipe : | None | |
| Included Heat Sink: | Integrated Light Pipe | |
| Packaging Method: | Tray | |
| Mating Components: | SFF-20 Series (x6) | |
| EMI Shielding Type: | EMI Spring Fingers |
Materials and Plating:
| EMI Shielding Material: | N/A | |
| Cage Material: | N/A | |
| Heat Sink Material: | N/A |
Environmental:
| Operating Temperature: | -40°C to +85°C | |
| Compliance: | Lead Free & RoHS Compliant |
Single Row Cage Part Number Configuration
Applications:
- Switch
- Router
- Server & Storage
- Fibre Channel and Gigabit Ethernet
- Networking & Telecommunication
