Introduction:
This 10G Ethernet RJ45 connector is engineered for high-bandwidth applications requiring 10G Base-T speeds. It adheres to Cat6a standards to provide ultra-fast data transmission for modern servers. The single port 8P8C modular jack features a stainless steel shield to prevent electromagnetic interference effectively. Its tab-up latch orientation and right-angle mounting simplify cable management in dense board layouts. Utilizing hi-temp thermoplastic, the component survives the intense heat of industrial wave soldering. Gold-plated copper alloy contacts ensure excellent electrical conductivity and resistance to oxidation. This through-hole jack provides a secure and durable mechanical connection for professional telecommunication systems.
Key Features
- 10G Cat6a Performance: Supports ultra-fast data transfer rates up to 10 Gbps.
- Stainless Steel Shielding: Metal housing blocks external electromagnetic interference effectively.
- Hi-Temp Thermoplastic: Durable housing withstands extreme industrial wave soldering temperatures.
- Tab-Up Orientation: Top-latch design facilitates easy cable insertion in layouts.
- Through Hole Mounting: Solder tails provide superior mechanical stability on PCBs.
Main Specifications:
General Information:
| Product No.: | MTJ-88TUX1-FS2-PG2T-C6A-HT | |
| Series: | MTJ | |
| Category: | High Speed RJ45 Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10G Base-T | |
| Performance Category: | CAT6a | |
| Integral Magnetics: | No | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shield | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.25A | |
| Rated Voltage: | 125V AC | |
| Contact Resistance: | N/A | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1000 VDC RMS 60Hz for 1 minute |
Materials and Plating:
| Housing Material: | Hi-temp Thermoplastic | |
| Housing Color: | Black | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold Plating | |
| Shield Material: | Stainless steel |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
