100W DIN Male to N-type Female RF Fixed Attenuator, DC to 4GHz
Introduction
This 100W DIN Mattenuator is a crucial component for achieving precise signal attenuation in a wide range of RF applications. Engineered for reliability and high performance, it boasts a DC to 4GHz frequency range and a low VSWR of 1.20:1, ensuring minimal signal reflection and optimal power transfer. Both the DIN male and N-type female connectors are constructed from durable stainless steel, providing excellent corrosion resistance and long-term stability in demanding environments.
Designed within the DIN Attenuator series, this fixed attenuator features a 50-ohm impedance, making it compatible with most standard RF systems. Its robust design is capable of handling up to 100 watts of power, making it suitable for high-power applications. With an IP20 protection rating and an expansive operating temperature range of -55°C to 125°C, this attenuator is built to perform consistently in harsh conditions, offering reliable signal reduction without compromising system integrity.
Key Features:
- High Power Handling: 100W power rating.
- Wide Frequency Range: DC to 4 GHz.
- Low VSWR: 1.20:1 for minimal signal reflection.
- Robust Construction: Stainless steel housing for durability.
- Standard Impedance: 50 Ohms for optimal signal matching.
- Broad Operating Temperature: -55°C to 125°C.
- Versatile Connectivity: DIN Male to N-type Female.
Main Specifications:
| Part No.: | 100W-DIN-N-JK-4G | |
| Product Series: | DIN Attenuators | |
| Brand: | Metabee | |
| Connector 1: | DIN Connector | |
| Connector 1 – Gender: | Male | |
| Connector 1 – Body Material: | Stainless Steel | |
| Connector 1 – Body Plating: | Not Applicable | |
| Connector 2: | N-type Connector | |
| Connector 2 – Gender: | Female | |
| Connector 2 – Body Material: | Stainless Steel | |
| Connector 2 – Body Plating: | Not Applicable | |
| Power Maximum: | 100W | |
| Attenuation: | 1DB, 3DB, 5DB, 6DB, 10DB, 15DB, 20DB, 30DB, 40DB, 50DB | |
| Impedance: | 50 Ohm | |
| VSWR: | ≤1.20:1 | |
| Frequency(Max): | 4 GHz | |
| Operating Temperature: | -55°C to +125°C | |
| IP Rating: | IP20 | |
| Other Feature: | None |
Applications of this 100W DIN Male to N-type Female RF Fixed Attenuator:
- Test & Measurement;
- Telecommunications;
- Satellite Systems;
- Broadcast Equipment;
- Military & Aerospace;
- Medical Devices;
- Wireless Networks;
- RF Amplifiers;
- Signal Generators.
We can provide the RF Attenuators according to your special requirements. Get a free quotation now!
