1 Port RJ45 Female Connector Socket with LEDs, 8P8C, Shielded with EMI, Tab-Up, Through Hole, R/A
Introduction:
This is a single port 8P8C shielded RJ45 female connector with LEDs designed for stable through hole mounting on networking circuit boards. It features a glass-reinforced PBT housing to ensure high mechanical stability and thermal resistance during industrial wave soldering processes. The nickel-plated brass shell provides a full shield against electromagnetic interference to maintain superior signal integrity in crowded electronic environments. Utilizing a Tab-Up right angle configuration, this component effectively optimizes vertical clearance while offering immediate diagnostics through built-in Green and Yellow status lights. Premium Phosphor Bronze contacts with Gold plating support a consistent 1.5A current rating and high insulation resistance. Technicians utilize this modular interface for telecommunication devices and industrial networking hardware requiring reliable data links.
Key Features
- Full EMI Shielding: Metallic brass shell blocks external signal interference.
- Integrated Status LEDs: Yellow and Green lights show connectivity status.
- Tab-Up Configuration: Optimizes vertical space for specialized board layouts.
- Gold Plated Contacts: Delivers superior conductivity and signal stability.
- Glass-Reinforced PBT: High-strength housing withstands intense industrial assembly heat.
Main Specifications:
General Information:
| Product No.: | MTJ-88ARX1-FSM-PG | |
| Series: | MTJ | |
| Category: | Single Port RJ45 Jack | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shield | |
| LED indicator: | Multiple combinations |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150V AC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC or 1500 VAC for 1 minute |
Materials and Plating:
| Insulator Material: | PBT, glass reinforced | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Brass, Nickel plated |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
