Introduction:
The component is a ganged 1×3 modular interface developed for high-density Ethernet networking applications. Three side-by-side 8P8C ports facilitate efficient multi-link board designs without the need for metal shielding. Reliable electrical performance is maintained within the 0C ~ 70C commercial temperature range for standard indoor environments. The grey PBT insulator provides high mechanical stability during the right angle through hole soldering process. Every port handles up to 1.5A current and 125VAC voltage for diverse telecommunication systems. Gold over nickel plating on phosphor bronze contacts strictly maintains electrical resistance below 35 miliohms. This tab-up version operates without visual LED indicators to suit streamlined board layouts. Typical uses include network hubs, industrial controllers, and multi-port telecommunication equipment.
Key Features
- Ganged 1×3 configuration: Connects three Ethernet links side-by-side efficiently.
- Unshielded 8P8C design: Streamlines board layout for cost-effective networking.
- Durable PBT housing: Ensures high mechanical stability during soldering.
- Low contact resistance: Gold-plated contacts maintain signal under 35 miliohms.
- Standard commercial range: Operates reliably between 0C and 70C.
Main Specifications:
General Information:
| Product No.: | MTJG-3-667HX2 | |
| Series: | MTJG | |
| Category: | Multi Port RJ45 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×3 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Interface Type: | Ganged | |
| Latch Direction: | Tab-Up | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Voltage: | 125VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 35mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Grey | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | 0°C to +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
