Introduction:
This 8-port SFP cage receptacle houses eight transceivers in a two-tier 2×4 stacked layout. It is a self-contained combo unit with built-in connectors, so it does not need extra SMT sockets. The outer copper alloy shell protects the ports and provides steady ground continuity. Integrated LPX light pipes route LED light to the front panel for clear link status checks. Around the front openings, EMI spring fingers block high-frequency electromagnetic noise. Durable phosphor bronze contacts ensure steady electrical signals over repeated insertions. Solderless press-fit pins press directly into PCB holes to hold the cage firmly without heat damage. This assembly works well in multi-port Ethernet switches, enterprise routers, and telecom systems.
Key Features
-
2×4 Stacked Layout: Houses eight transceiver ports across a bi-level footprint.
-
Enhanced LPX Light Pipes: Routes board-level optical link indicators to front panel.
-
Integrated Combo Receptacle: Eliminates discrete SMT connectors to streamline PCB assembly.
-
Solderless Press-Fit Pins: Secures board retention without thermal wave soldering stress.
-
Copper Alloy EMI Fingers: Grounds chassis openings to block electromagnetic emissions.
Main Specifications:
General Information:
| Product No.: | SFCJ-8-LPX-CS1 | |
| Product Type: | Cage and Connector Combo | |
| Pluggable Form Factor: | SFP | |
| Port Configuration: | 8 Ports (2×4 Stacked) | |
| PCB Mounting Style: | Press-Fit | |
| Included Lightpipe : | Enhanced Light Pipe (LPX) | |
| Included Heat Sink: | None | |
| Packaging Method: | Tray | |
| Mating Components: | Self-Contained (No separate socket needed) | |
| EMI Shielding Type: | EMI Spring Fingers |
Materials and Plating:
| EMI Shielding Material: | N/A | |
| Cage Material: | Copper Alloy | |
| Insulator Material: | LCP, UL 94V-0 | |
| Connector Insert Material: | Hi-temp thermoplastic, UL 94V-0 | |
| Contact Material: | Phosphor Bronze |
Environmental:
| Operating Temperature: | N/A | |
| Compliance: | Lead Free & RoHS Compliant |
Single Row Cage Part Number Configuration
Applications:
- Switch
- Router
- Server & Storage
- Fibre Channel and Gigabit Ethernet
- Networking & Telecommunication
