SATA Female Combo Data & Power Connector, 29 Pin, SMT, Vertical
Introduction:
The sata female combo data & power connector, 29 pin, smt, vertical is engineered for high-performance enterprise storage, server backplanes, and data-intensive computing architectures. Featuring a high-density dual-port configuration with a 7+15+7 pin arrangement totaling 29 positions, this female receptacle integrates dual data channels and power delivery into a single unified interface. Its vertical mounting profile conserves board area while surface mount technology ensures rapid, precise automated smt processing and reliable coplanarity.
Constructed to meet exacting signal integrity demands, this component supports a 1.5 a current rating alongside a maximum contact resistance of 30 mohms and a minimum insulation resistance of 1,000 mohms to eliminate data loss and cross-talk. The robust housing carries a ul94v-0 flame-retardant rating, backed by a 500 vac dielectric withstanding voltage and an expansive operating temperature range from -55°c to 85°c for continuous industrial reliability.
Key Features
- Dual-port 29 pin combo interface combining high-speed data and power.
- 7+15+7 female contact configuration for versatile drive compatibility.
- Vertical board-mount orientation optimizes high-density pcb footprints.
- Surface mount technology ensures fast, automated assembly accuracy.
- 1.5 a rated current with 30 mohms max contact resistance.
- Ul94v-0 flame-retardant housing rated for -55°c to 85°c operation.
Main Specifications:
General Information:
| Product No.: | SATA-A13-PM-SMT-P-C-15 | |
| Connector Series: | SATA Connectors | |
| Brand: | Metabee | |
| Number of Contacts: | 7+15+7 Pin | |
| Number of Ports: | Dual Port | |
| Connector Gender: | Female | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | SMT | |
| Polarization: | Middle Polarization | |
| Mating Cycles: | 500 Cycles | |
| Other Feature: | None |
Materials and Plating:
| Contact Material: | Brass | |
| Plating: | Gold flash over nickel underplate on mating area, Tin over nickel underplate on tails |
|
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Current rating: | 1.5 ampere per contact. | |
| Contact resistance: | 30 mOhms max. | |
| Insulation resistance: | 1,000 Mohms min | |
| Dielectric withstanding voltage: | 500 VAC |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -55℃ to +85℃ |
Part Number Configuration
Applications:
SATA Connector is an interface system for connecting SATA storage devices to host systems, primarily supporting data transmission and power delivery in HDDs, SSDs, servers, NAS systems, and industrial computers.
Here are some key applications:
- Computer Systems
- Storage Systems
- Servers
- Industrial Equipment
- Consumer Electronics
