RJ45 Modular Jack 8P8C Ethernet Connector without LEDs, 1 Port, Tab-Up, Through Hole, R/A
Introduction:
This is a single port RJ45 modular jack connector designed for stable right angle through hole mounting on networking circuit boards. It features a glass reinforced PBT housing for superior thermal stability and structural strength during industrial soldering processes. The 8P8C interface utilizes Phosphor Bronze contacts with a Gold over Nickel finish to ensure a low resistance path and a consistent 1.5A current rating. Utilizing a Tab-Up configuration, this unshielded component maintains a high insulation resistance of 1000MΩ Min across a wide temperature range of -40°C to +85°C. Technicians utilize this reliable interface for standard telecommunication equipment and networking hardware requiring stable data links without external shielding.
Key Features
- Tab-Up Configuration: Optimizes vertical board clearance for specialized layouts.
- Glass Reinforced PBT: Ensures durable structural and high thermal stability.
- Gold Plated Contacts: Provides superior conductivity and lasting signal integrity.
- High Insulation Resistance: Maintains 1000MΩ Min for enhanced electrical safety.
- Wide Temperature Range: Performs reliably between -40°C and +85°C.
Main Specifications:
General Information:
| Product No.: | MTJ-88ARX1 | |
| Series: | MTJ | |
| Category: | Single Port RJ45 Jack | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Latch Direction: | Tab-Up | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150V AC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VDC/AC peak for 1 minute |
Materials and Plating:
| Housing Material: | PBT, glass reinforced | |
| Housing Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
