Introduction:
This straight 12-pin female magnetic pogo pin connector provides a reliable, high-density docking socket for multi-channel power and data transmission. Featuring a compact rectangular profile with a vertical straight mounting layout, it maximizes board space utilization while simplifying PCB trace integration. The durable black LCP insulator offers high thermal stability during surface-mount soldering. Built-in polarized magnets guide effortless auto-alignment to prevent reverse mating, while precision flat target contacts ensure smooth, low-wear electrical engagement. It serves as an ideal female docking receptacle for testing stations, smart handheld terminals, and modular electronics.
Key Features
- 12-Pin High-Density Socket: Compact rectangular layout maximizes multi-channel connection efficiency.
- Magnetic Auto-Alignment: Polarized magnets ensure fast, error-free blind mating.
- High-Temperature LCP: Heat-resistant black housing withstands demanding reflow processes.
- Vertical Straight Profile: Straight PCB orientation saves critical board surface area.
- Flat Target Contacts: Precision female pads minimize wear during mating cycles.
Main Specifications:
General Information:
| Product No.: | PH2-C272-12-FVP-76 | |
| Product Type: | Magnetic Pogo Pin Connector | |
| Pin Configuration: | 12 Pin | |
| Connector Gender: | Female | |
| Connector Shape: | Rectangular | |
| Mounting Orientation: | Straight | |
| Pitch(mm): | 2.00mm | |
| Working Stroke (mm): | N/A | |
| Life Test: | N/A |
Electrical:
| Rated Current: | N/A | |
| Rated Voltage: | N/A | |
| Contact Resistance: | N/A |
Materials and Plating:
| Insulator Material: | LCP | |
| Insulator Color: | Black | |
| Contact Material: | N/A | |
| contact plating: | N/A | |
| Spring Material: | N/A | |
| Magnet: | N/A |
Environmental:
| Operating Temperature: | N/A | |
| Flammability Rating: | UL 94 V-0 |
Structure of Magnetic Pogo Pin Connector
Applications:
Magnetic pogo pin connectors combine spring-loaded pin technology with magnetic alignment, providing reliable electrical contact and quick connection for power and signal transmission. Their magnetic design enables easy mating, secure attachment, and repeated connection cycles.
- Consumer Electronics
- Wearable Devices
- Charging Docks & Cradles
- Smart Home & IoT Devices
- Medical Equipment
- Industrial Equipment
- Automotive Electronics
- Custom OEM & ODM Solutions
