One Port Unshielded RJ45 Modular Jack, 8P8C, Tab-Up, Through Hole, R/A, No LED
Introduction:
This is a single port unshielded RJ45 modular jack designed for stable through hole mounting on networking circuit boards. It is built with a black Nylon66 housing that provides reliable structural strength and maintains an insulation resistance of 500MΩ Min. The Phosphor Bronze contacts feature a durable Gold over Nickel finish to ensure superior conductivity and a standard 1.5A current rating. Utilizing a Tab-Up right angle configuration, this component optimizes vertical board space while handling operating temperatures from -40°C to +85°C for long-term consistency. Technicians utilize this modular interface for networking systems and telecommunication hardware requiring secure, unshielded 8P8C connectivity.
Key Features
- Tab-Up Design: Optimizes vertical clearance for specialized PCB layouts.
- Gold Plated Contacts: Delivers superior conductivity and lasting signal stability.
- 8P8C RJ45 Interface: Provides standard modular connectivity for networking systems.
- Nylon66 Housing: Ensures durable performance within -40 to +85°C environments.
- High Current Support: Handles up to 1.5A for efficient power delivery.
Main Specifications:
General Information:
| Product No.: | MTJ-887X1 | |
| Series: | MTJ | |
| Category: | Single Port RJ45 Jack | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Latch Direction: | Tab-Up | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150V AC | |
| Contact Resistance: | 25mΩ Max | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Housing Material: | Nylon66 | |
| Housing Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
