Introduction:
The component is a ganged 1×2 modular interface designed for high-density Ethernet networking applications. Standard 8P8C ports facilitate reliable data transmission for various communication systems. Successful operation is sustained across an extreme -40C to +125C industrial temperature range for severe environments. A robust grey PBT insulator houses phosphor bronze contacts with gold over nickel plating to ensure housing integrity. Low electrical resistance stays strictly below 20 miliohms to guarantee flawless signal clarity. Secure board integration relies on the right angle through hole mounting configuration. Streamlined visuals are achieved by the no LED profile in this version. Modern network switches, industrial hubs, and automated control systems frequently utilize this product.
Key Features
- Ganged 1×2 configuration: Provides two side-by-side network ports efficiently.
- Industrial temperature range: Operates reliably from -40C up to +125C.
- Unshielded 8P8C design: Optimizes board space for cost-effective hubs.
- Durable PBT housing: Polyamide insulation ensures high mechanical stability.
- Low resistance contacts: Gold plating ensures strictly under 20 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJG-2-66NX1 | |
| Series: | MTJG | |
| Category: | Multi Port RJ45 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×2 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Interface Type: | Ganged | |
| Latch Direction: | Tab-Up | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Grey | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -40°C to +125°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
