Introduction:
Side-by-side network integration relies on the multi port rj45, which features a compact 1×4 ganged interface for high-density board layouts. Reliable data transmission is maintained through four separate 8P8C ports for standard Ethernet networking. Successful performance is sustained across a wide -40C ~ +70C temperature range to ensure stability in various industrial environments. The yellow hi-temp thermoplastic insulator provides robust housing integrity during the right angle through hole termination process. High-quality phosphor bronze contacts with gold over nickel plating strictly maintain electrical resistance below 30 miliohms. Visual indicators are omitted for this streamlined tab-down profile. Modern network switches, telecom hubs, and industrial controllers frequently utilize this multi port rj45.
Key Features
- Ganged 1×4 configuration: Connects four network devices side-by-side efficiently.
- Industrial temperature range: Operates reliably from -40C up to +70C.
- Unshielded UTP design: Optimizes board space for cost-effective hubs.
- Hi-temp thermoplastic housing: Ensures structural integrity during THT soldering.
- Low resistance contacts: Gold plating maintains conductivity below 30 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJG-4-88TX1-P114C-HT-A | |
| Series: | MTJG | |
| Category: | Multi Port RJ45 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×4 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Interface Type: | Ganged | |
| Latch Direction: | Tab-Down | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 30mΩ Max | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Insulator Material: | Hi-temp thermoplastic | |
| Insulator Color: | Yellow | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -40°C to +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
