Introduction:
High-density networking configurations benefit from the multiple RJ45 sockets, which feature a 1×4 ganged interface for industrial systems. Reliable Ethernet performance is maintained through four separate 8P8C ports for standard communication. Consistent operation remains stable throughout the wide -40C to +85C industrial temperature range. Protection from electromagnetic interference comes from a robust nickel plated copper alloy shield enclosing the black PBT housing. Secure mechanical termination relies on a right angle THT configuration with built-in board locks. Gold over nickel plating on phosphor bronze contacts strictly maintains electrical resistance below 20 miliohms. Industrial network switches, server motherboards, and automated controllers frequently utilize this specialized module.
Key Features
- Ganged 1×4 configuration: Connects four network devices side-by-side efficiently.
- Industrial temperature range: Operates reliably between -40C and +85C.
- Full metal shielding: Blocks severe electromagnetic interference for clear signals.
- Durable PBT housing: Ensures high mechanical stability for PCB integration.
- Low contact resistance: Gold plating maintains strictly under 20 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJG-4-88GX1-FSB-PG | |
| Series: | MTJG | |
| Category: | Multi Port RJ45 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×4 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Interface Type: | Ganged | |
| Latch Direction: | Tab-Down | |
| Shielding: | Full Shield | |
| LED indicator: | No LED |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1500 Vrms for 1 minute |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | -40°C to +85°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
