L1 Band GPS Antenna, SMA Male with RG174 Cable, 1575.42MHz, 5dBi, IP67
Introduction:
Upgrade your positioning systems with this L1 Band GPS Antenna, tuned precisely to 1575.42 MHz for reliable satellite tracking. Delivering 5dBi gain with an omnidirectional radiation pattern, it captures weak GNSS signals from all directions, ensuring consistent lock performance for vehicle tracking, fleet management, and marine navigation. The antenna features a SMA Male connector pre-attached with RG174 cable, offering flexible installation in tight or weather-exposed locations thanks to its lightweight and low-loss design.
Built for rugged outdoor use, the IP67-rated housing provides complete dust protection and withstands water immersion up to 1 meter. With a VSWR of ≤1.92, vertical polarization, and 50W max input power at 50 Ohm impedance, this antenna minimizes signal reflection and maximizes efficiency. It operates flawlessly across -30°C to +75°C, making it a durable choice for GPS, GLONASS, and Galileo L1 applications in harsh environments.
Key Features
- L1 Band 1575.42 MHz – Optimized for GPS/GNSS precision tracking
- 5dBi Gain & Omnidirectional – Stable signal from any direction
- SMA Male + RG174 Cable – Flexible, easy routing in tight spaces
- IP67 Rated – Fully dust-tight and waterproof for outdoor use
- Low VSWR ≤1.92 – High-efficiency, low-reflection performance
- -30°C to +75°C Operation – Reliable in extreme temperatures
General Information:
| Product No.: | GP00019 | |
| Connector Series: | GPS/GNSS Antennas | |
| Brand: | Metabee | |
| Connector Type: | SMA Male or Customized | |
| Connector Orientation: | Straight | |
| Casing Material: | ASA | |
| IP Rating: | IP67 | |
| Operating Temperature: | -30℃ to +75℃ | |
| Color: | Black | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 1575.42 MHz | |
| Gain: | 5dBi | |
| VSWR: | ≤1.9 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omni-directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
GPS/GNSS Antennas
GPS/GNSS Antenna Structure
Applications of this L1 Band GPS Antenna:
GPS antennas are crucial for various applications across many industries, enabling precise location, navigation, and timing.
Here are some key applications:
- Automotive Navigation and Fleet Management
- Consumer Devices
- Surveying and Mapping
- Aviation
- Marine Applications
- Drones and UAVs
- Agriculture
- Emergency Services
- Industrial IoT (Internet of Things)
- Scientific Research and Geodetic Surveying
