GPS L1 Band Outdoor Antenna, SMA Male with 1m RG174 Cable, 1575.42MHz, 5dBi
Introduction:
This GPS L1 band outdoor antenna is designed for reliable satellite positioning and stable GNSS signal reception at 1575.42 MHz. Featuring an omnidirectional radiation pattern and vertical polarization, it delivers consistent coverage for navigation, tracking, automotive, and industrial positioning applications.
With a 5dBi gain and 50 Ohm impedance, the antenna ensures efficient RF transmission and enhanced signal stability. A VSWR of ≤1.92 minimizes signal reflection for optimized performance in demanding environments. The SMA male connector combined with a 1m RG174 cable enables flexible and convenient installation across a wide range of GPS devices and GNSS systems.
Built for outdoor durability, the antenna features an IP67-rated enclosure for complete protection against dust and water ingress. Operating reliably from -30°C to +75°C, it is suitable for long-term deployment in harsh environmental conditions.
Key Features
- 1575.42 MHz GPS L1 frequency for precise positioning
- 5dBi gain with omnidirectional signal coverage
- Vertical polarization for stable satellite reception
- VSWR ≤1.92 with 50 Ohm impedance for efficient RF performance
- IP67-rated waterproof and dustproof outdoor design
- SMA Male connector with 1m RG174 cable for flexible installation
General Information:
| Product No.: | YC-GP00008 | |
| Connector Series: | GPS/GNSS Antennas | |
| Brand: | Metabee | |
| Connector Type: | SMA Male | |
| Connector Orientation: | Straight | |
| Casing Material: | ASA | |
| Size: | – | |
| IP Rating: | IP67 | |
| Operating Temperature: | -30℃ to +75℃ | |
| Color: | Black | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 1575.42 MHz | |
| Gain: | 5dBi | |
| VSWR: | ≤1.9 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omni-directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
GPS/GNSS Antennas
GPS/GNSS Antenna Structure
Applications of this GPS L1 Band Outdoor Antenna:
GPS antennas are crucial for various applications across many industries, enabling precise location, navigation, and timing.
Here are some key applications:
- Automotive Navigation and Fleet Management
- Consumer Devices
- Surveying and Mapping
- Aviation
- Marine Applications
- Drones and UAVs
- Agriculture
- Emergency Services
- Industrial IoT (Internet of Things)
- Scientific Research and Geodetic Surveying
