GPS L2 Band Antenna with N Male, 1227.60 MHz, 5dBi, IP67
Introduction:
Optimize your GPS L2 Band applications with our high-performance L2 Band GPS Antenna, expertly designed for precision signal acquisition and unwavering stability. This antenna delivers advanced positioning data, crucial for demanding systems that require enhanced accuracy and resilience across diverse operational environments. Its omni-directional radiation pattern ensures broad and reliable signal reception, providing comprehensive coverage for critical outdoor deployments.
Specifically tuned to the 1227.60 MHz frequency, this antenna boasts a robust 5dBi gain, significantly enhancing signal strength and clarity within the GPS L2 spectrum. With a Voltage Standing Wave Ratio (VSWR) of ≤1.92 and vertical polarization, it minimizes signal reflection and maximizes transmission efficiency. The design is engineered to handle a maximum input power of 50W and features a standard 50 Ohm impedance, ensuring seamless integration with a wide array of GPS receivers. Connectivity is reliably established via an N Male connector equipped with a durable RG174 cable. Furthermore, the IP65 rating guarantees protection against dust and water jets, ensuring consistent performance in temperatures ranging from -30 °C to 75 °C.
Key Features
- L2 Band Optimization: Precisely tuned for 1227.60 MHz GPS L2 signal reception.
- High 5dBi Gain: Provides superior signal amplification for enhanced accuracy.
- Omni-directional Coverage: Ensures consistent signal acquisition from all directions.
- IP65 Weatherproof: Offers robust protection against dust and water jets.
- Wide Operating Temperature: Functions reliably from -30 °C to 75 °C.
- N Male Connector: Facilitates secure and efficient connectivity with RG174 cable.
General Information:
| Product No.: | YC-GP00029 | |
| Connector Series: | GPS/GNSS Antennas | |
| Brand: | Metabee | |
| Connector Type: | N Male or Customized | |
| Connector Orientation: | Straight | |
| Casing Material: | ASA | |
| Size: | – | |
| IP Rating: | IP67 | |
| Operating Temperature: | -30℃ to +75℃ | |
| Color: | Black | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 1227.60 MHz | |
| Gain: | 5dBi | |
| VSWR: | ≦1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omni-directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
GPS/GNSS Antennas
GPS/GNSS Antenna Structure
Applications of this GPS L2 Band Antenna with N Male:
GPS antennas are crucial for various applications across many industries, enabling precise location, navigation, and timing.
Here are some key applications:
- Automotive Navigation and Fleet Management
- Consumer Devices
- Surveying and Mapping
- Aviation
- Marine Applications
- Drones and UAVs
- Agriculture
- Emergency Services
- Industrial IoT (Internet of Things)
- Scientific Research and Geodetic Surveying
