Introduction:
The ganged RJ45 connectors provide a compact 1×4 multi-port interface for high-density network systems. Every module supports reliable data transmission with a 1.5A current rating for standard Ethernet equipment. Operational stability remains consistent throughout the -40C ~ +70C temperature range in diverse industrial settings. Full protection against electromagnetic interference comes from a robust nickel plated copper alloy shield. Yellow hi-temp thermoplastic serves as the durable insulator to withstand thermal stress during right angle through hole termination. Gold over nickel plating on phosphor bronze contacts strictly maintains electrical resistance below 30 miliohms. Visual indicators are omitted for this streamlined tab-up profile. Networking switches, multi-link hubs, and industrial controllers frequently incorporate these ganged RJ45 connectors to maximize board efficiency.
Key Features
- Ganged 1×4 configuration: Facilitates four network ports side-by-side efficiently.
- Full metal shielding: Blocks severe electromagnetic interference for clear signals.
- Industrial temperature range: Operates reliably from -40C up to +70C.
- High-temp thermoplastic: Ensures structural integrity during soldering processes.
- Low resistance contacts: Gold finish ensures conductivity below 30 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJG-4-88ARX1-FSW-P114C-HT-A | |
| Series: | MTJG | |
| Category: | Multi Port RJ45 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×4 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Interface Type: | Ganged | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shield | |
| LED indicator: | No LED |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 30mΩ Max | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC |
Materials and Plating:
| Insulator Material: | Hi-temp thermoplastic | |
| Insulator Color: | Yellow | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | -40°C to +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
