Introduction:
The dual stacked RJ45 is a high-density 2×3 multi-port network interface designed for Gigabit Ethernet applications. Reliable 1000 Base-T data speeds remain consistent throughout the extreme -40 to 85 degrees Celsius industrial temperature range. A robust stainless steel shield encloses the black thermoplastic housing to block electromagnetic interference effectively during high-speed traffic. Visual network link status is monitored through integrated green and green/yellow LED indicators positioned in the stacked profile. Mechanical stability on the PCB depends on right-angle through hole termination paired with board guide and solder retention features. Furthermore, gold-plated phosphor bronze contacts strictly maintain low electrical resistance in this dual-stacked RJ45.
Key Features
- 1000 Base-T Performance: Handles high-speed Gigabit Ethernet data transmission flawlessly.
- 2×3 Multi-Port Design: Connects six network devices using a single module.
- Industrial Temperature Range: Operates reliably across extreme -40 to 85 degrees Celsius.
- Stainless Steel Shielding: Blocks severe electromagnetic interference for clear signals.
- Secure THT Mounting: Board guides and solder retention ensure stability.
Main Specifications:
General Information:
| Product No.: | MTJG-6-88JX1-FSG-PG-L35-M150Y-WOT | |
| Series: | MTJ | |
| Category: | RJ45 Magnetic Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 2×3 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 1000 Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non PoE | |
| Latch Direction: | Tab-Up & Down | |
| Shielding: | Full Shielded | |
| LED indicator: | Left: Green, Right: Green/Yellow |
Electrical:
| Rated Voltage: | N/A | |
| Contact Resistance: | N/A | |
| Insulation Resistance: | 500mΩ Min |
Materials and Plating:
| Insulator Material | Thermoplastic | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Stainless Steel |
Environmental:
| Operating Temperature: | -40°C ~ +85°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
