Black Plastic Housing RJ11 Phone Jack Connector, 6P4C, 1 Port, Unshielded, Through Hole, R/A, Tab-Up, No LED
Introduction:
This is a single port rj11 phone jack connector featuring a black plastic housing designed for stable right angle through hole mounting on printed circuit boards. It is constructed with durable PBT material that maintains structural integrity across a temperature range of -40°C to +85°C. Gold plated Phosphor Bronze contacts ensure superior conductivity and support a standard 1.5A current rating for voice and data signals. Utilizing a Tab-Up configuration, the unshielded jack effectively saves vertical space while providing a high insulation resistance of 1000 mohms. The component handles dielectric withstanding voltages up to 1500 VDC to maintain electrical safety in various circuits. Technicians utilize this reliable interface for standard telephone systems and networking gear requiring secure board-to-cable links.
Key Features
- 6P4C RJ11 Interface: Provides standard modular connectivity for voice systems.
- Tab-Up Orientation: Optimizes vertical space for specialized board layouts.
- Gold Plated Contacts: Delivers superior conductivity and lasting signal stability.
- Durable PBT Housing: Maintains structural integrity across standard temperature ranges.
- High Insulation Resistance: Ensures 1000 mohms for enhanced electrical safety.
Main Specifications:
General Information:
| Product No.: | MTJ-642BX2 | |
| Series: | MTJ | |
| Category: | Single Port RJ11 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 6P4C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Latch Direction: | Tab-Up | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150V AC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC or 1500 VDC for 1 minute |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | 40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
