2.8mm High Voltage Interlock Loop 3 Pin Cable, Plug, A Key, 4mm², 23A
Introduction
The 2.8mm High Voltage Interlock Loop (HVIL)cable is designed for secure and efficient interlock connections in electric vehicles, battery systems, and high-voltage control units. Featuring a straight plug configuration, it provides excellent cable routing flexibility in compact installation environments. With a 2.8mm terminal diameter and 4mm² wire gauge, this HVIL cable supports up to 23A at 1000V, ensuring stable signal transmission and circuit protection for high-voltage systems.
Manufactured with a zinc alloy housing and nickel-plated copper alloy contacts, the connector offers outstanding conductivity, corrosion resistance, and mechanical strength. The A Key design ensures precise alignment and secure mating, minimizing connection errors. Engineered to meet IP67 ingress protection and UL94V-0 flame retardant standards, it delivers reliable performance under harsh environmental conditions and operates safely from -40°C to +125°C.
Compact, durable, and safety-certified, this HVIL cable is an ideal choice for EV power distribution, battery management, and high-voltage safety circuits, providing long-term stability and protection.
Key Features:
- Rated 1000V/23A for high-voltage interlock systems.
- 3 Pin Straight Plug with A Key for secure and accurate connection.
- Nickel-plated copper contacts for optimal conductivity and corrosion resistance.
- IP67 waterproof and dustproof protection.
- UL94V-0 flame-retardant housing for high safety standards.
- Reliable performance from -40°C to +125°C in extreme environments.
Main Specifications:
General Information:
| Part No.: | NI2-1-S280- 3AYA-C04-L0.1 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 3 Pin | |
| Shell Material: | PA66+GF | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 2.8mm | |
| Wire Gauge: | 4mm² | |
| Cable length: | 10cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 23A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 2.8mm High Voltage Interlock Loop 3 Pin Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
