3.6mm High Voltage Interlock Loop HV Automotive 2 Pin Cable, Plug, A Key, 10mm², 50A
Introduction
This 3.6mm HVILable Assembly is engineered for robust performance in demanding automotive and industrial high-voltage applications. Designed as a 2-pin straight plug with an A Key configuration, it ensures correct mating and prevents mismating in complex systems. The assembly features a durable PA66+GF connector housing and a nickel-plated copper alloy contact, offering excellent resistance to heat, chemicals, and corrosion. With a substantial 10mm² wire gauge, it is built to efficiently handle high-power transmissions.
The component is rated for 1000V and 50A, ensuring reliable operation in high-power circuits. Its IP67 rating guarantees complete protection against dust and temporary immersion in water, while the UL94V-0 flammability rating ensures high resistance to fire. Engineered for extreme environments, it operates flawlessly across a wide temperature range from -40°C to +125°C, making it a dependable choice for electric vehicles and other high-voltage machinery.
Key Features:
- 3.6mm Terminal Diameter, 2-Pin Socket with A Key
- Rated for 1000V / 35A High Voltage & Current
- IP67 Rated for Dust and Water Resistance
- UL94V-0 Flame-Retardant Material (PA66+GF)
- Nickel-Plated Copper Alloy for Superior Conductivity
- Wide Operating Temperature: -40°C to +125°C
Main Specifications:
General Information:
| Part No.: | NI2-1-S036- 2AYA-C06-L0.1 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 2 Pin | |
| Shell Material: | PA66+GF | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 3.6mm | |
| Wire Gauge: | 10mm² | |
| Cable length: | 10cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 50A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 3.6mm High Voltage Interlock Loop HV Automotive 2 Pin Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
