3.6mm HVIL High Voltage Interlock Loop 3 Pin Cable, Socket, A Key, 6mm², 35A
Introduction
Ensure the utmost safety and reliability in your high-voltage systems with this premium 3.6mm HVIL (High Voltage Interlock Loop) Cable. Specifically designed for electric vehicle (EV) and hybrid applications, this cable assembly features a straight, 3-pin Socket connector with A Key coding to prevent mismating. The robust construction includes a durable Zinc Alloy shell and high-conductivity Copper Alloy contacts with Nickel-Plating, guaranteeing superior mechanical strength and corrosion resistance. Rated for an exceptional 1000V voltage and 35A current, this HVIL cable is an essential component for secure power transmission.
The cable provides maximum operational integrity under challenging conditions. With an IP67 ingress protection rating, it is fully sealed against dust and immersion in water, while the UL94V-0 flame-retardant rating ensures critical fire safety. Performance is reliable across an extreme operating temperature range of -40°C to 125°C. The precise 3.6mm terminal diameter and 6mm² wire gauge (10cm length) optimize current handling and system integration, making it the ideal choice for battery packs, inverters, and high-voltage distribution units.
Key Features:
- High-Safety HVIL: Integrated High Voltage Interlock Loop for critical safety and circuit integrity monitoring.
- Robust Electrical Ratings: High capacity performance with a 1000V voltage and 35A current rating.
- Extreme Environmental Protection: IP67 waterproof/dustproof rating and UL94V-0 flame retardancy.
- Heavy-Duty Construction: Durable Zinc Alloy shell and Nickel-Plated Copper Alloy contacts.
- Optimal High-Current Flow: Features 3.6mm terminal diameter and 6mm² wire gauge.
- Wide Temperature Range: Reliable operation from -40°C to 125°C for harsh environments.
Main Specifications:
General Information:
| Part No.: | NI1-1-H036-3AYN-C05-L0.1 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Socket | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 3 Pin | |
| Shell Material: | PA66+GF | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 3.6mm | |
| Wire Gauge: | 6mm² | |
| Cable length: | 10cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 35A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 3.6mm HVIL High Voltage Interlock Loop 3 Pin Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
