6mm High-Quality High Voltage Interlock Loop EV Cable, 2 Pin Plug, A Key, 25mm², 125A, Right Angle
Introduction
This 6mm HVIL cable is engineered for superior performance and reliability in electric vehicle (EV) high-voltage systems. Featuring a robust 2-Pin Plug with an A Key configuration and a space-saving right-angle design, it ensures secure and correct mating while simplifying installation in tight spaces. The cable is constructed with a durable zinc alloy connector shell and nickel-plated copper alloy contacts, offering excellent conductivity and corrosion resistance. With a substantial 25mm² wire gauge, it is rated for high-power applications, capable of handling up to 1000V and 125A.
Built to withstand demanding environments, this HVIL cable assembly boasts an IP67 rating, providing complete protection against dust and temporary immersion in water. It meets the UL94V-0 flammability standard, significantly reducing the risk of fire propagation. The assembly remains fully operational across an extensive temperature range from -40°C to 125°C, ensuring consistent performance in both extreme cold and heat. The 50cm length provides practical flexibility for various routing needs within the vehicle’s architecture.
Key Features:
- 6mm Terminal, 25mm² Wire, 50cm Length
- 2-Pin Right-Angle Plug with A Key
- Rated for 1000V / 125A
- IP67 Rated for Dust & Water Resistance
- UL94V-0 Flame Retardant
- Operating Temperature: -40°C to +125°C
Main Specifications:
General Information:
| Part No.: | NI1-1-B060-2AYN-C08-L0.5 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Right Angle | |
| Connector Coding: | A Key | |
| Number of Positions: | 2 Pin | |
| Shell Material: | Zinc Alloy | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 6mm | |
| Wire Gauge: | 25mm² | |
| Cable length: | 50cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 125A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 6mm High-Quality High Voltage Interlock Loop EV Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
