Introduction:
Side-by-side connectivity relies on the ganged RJ45 connector, which integrates two 8P8C ports into a single footprint for high-density board designs. Reliable data transmission across standard Ethernet links is maintained across an extreme industrial temperature range from -40C up to 85C. Robust black PA66 insulation ensures long-term housing integrity during secure through hole board installations. Precise mechanical alignment onto the PCB depends on the right-angle termination profile. High-quality phosphor bronze contacts with gold over nickel plating strictly maintain electrical resistance below 20 miliohms in this ganged RJ45 connector. Every port provides consistent performance without the need for visual LED indicators. Network switches, industrial computers, and automated control systems commonly utilize these durable multi-port sockets.
Key Features
- Ganged 1×2 configuration: Facilitates two side-by-side network ports.
- Industrial temperature range: Operates reliably between -40C and 85C.
- Unshielded 8P8C interface: Streamlines networking for dense board layouts.
- Durable PA66 housing: Ensures high mechanical stability for PCB.
- Low resistance contacts: Gold plating maintains strictly under 20 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJG-2-88GX1 | |
| Series: | MTJG | |
| Category: | Multi Port RJ45 Jack | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×2 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Interface Type: | Ganged | |
| Latch Direction: | Tab-Down | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VDC or AC Peak for 1 minute |
Materials and Plating:
| Insulator Material: | PA66 | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -40°C to +85°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
