USB-C 2.0 Receptacle, 24 Pin, 480 Mbps, Upright
Introduction:
USB-C 2.0 is engineered for reliable data transmission and stable power delivery in compact electronic assemblies. Featuring a single-port Type-C interface with a full 24-pin configuration, this upright receptacle supports data rates up to 480 Mbps in compliance with USB 2.0 standards. The vertical design enables efficient PCB layout and secure integration in space-limited devices, making it suitable for consumer electronics, embedded systems, and industrial applications.
The connector housing is constructed from stainless steel with a nickel-plated finish, ensuring excellent mechanical strength, corrosion resistance, and EMI shielding performance. Copper alloy contacts with gold plating provide low contact resistance, enhanced conductivity, and extended mating life. Rated at 5A and 5V, this USB-C 2.0 receptacle supports dependable power transmission while maintaining consistent electrical performance.
Compliant with UL94V-0 flame-retardant standards, the connector operates reliably within a wide temperature range of -40°C to +85°C. It offers a durable, cost-effective interconnect solution for USB-C 2.0 applications that require long-term stability and environmental resilience.
Key Features
- USB-C 2.0 receptacle, single-port configuration
- 24-pin interface supporting 480 Mbps data transfer
- Upright (vertical) mounting design
- Stainless steel shell with nickel plating
- Gold-plated copper alloy contacts
- Rated 5A, 5V, UL94V-0, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C20-S-RU-CS2A-BL-BK | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin (14+10 Dummy) | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | 5V |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB-C 2.0 Receptacle, 24 Pin, 480 Mbps:
USB 4.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
