USB-C 2.0 Plug, 24 Pin, 480 Mbps, PCB Mount, Vertical
Introduction:
Optimize your hardware interface with this premium USB 2.0 Type-C Male Plug. Engineered for high-density PCB layouts, this 24-pin connector supports reliable data transfer rates of up to 480 Mbps. Its right-angle orientation and robust PCB mounting design provide exceptional mechanical stability, making it an ideal choice for compact consumer electronics and industrial peripherals.
Constructed for longevity, the connector features a nickel-plated stainless steel shell for superior EMI shielding and corrosion resistance. The internal copper alloy contacts are finished with gold plating to ensure maximum conductivity and signal integrity even after repeated mating cycles. Rated for a 5A current and built with UL94V-0 flame-retardant materials, it operates reliably across a wide temperature range of -40°C to 85°C, ensuring peak performance in demanding environments.
Key Features
- High-Speed Connectivity: Supports USB 2.0 protocols with data rates up to 480 Mbps.
- Rugged Durability: Nickel-plated stainless steel shell for enhanced wear resistance.
- Superior Conductivity: Gold-plated copper alloy contacts support a high 5A current rating.
- Precision Engineering: Right-angle 24-pin configuration designed for stable PCB mounting.
- Thermal Resilience: Industrial-grade operating range from -40°C to 85°C.
- Safety Guaranteed: UL94V-0 certified flame retardancy for critical protection.
Main Specifications:
General Information:
| Product No.: | YC-USB-C20-PLUG-R1-BK-HT-PP | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin(16+8 Dummy) | |
| Number of Ports: | Single Port | |
| Connector Gender: | Plug | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB-C 2.0 Plug, 24 Pin, 480 Mbps:
USB 4.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
