USB-C 2.0 Connector, Receptacle, 24 Pin, 480 Mbps, R/A, Waterproof
Introduction:
USB-C 2.0 is engineered for reliable data transmission and compact PCB integration. Featuring a single-port USB Type-C interface with a full 24-pin configuration, this receptacle supports data rates up to 480 Mbps in accordance with USB 2.0 standards. The right-angle PCB mount design optimizes board space while ensuring secure mechanical stability in high-density electronic assemblies.
Constructed with a stainless steel shell and nickel-plated finish, the connector provides excellent corrosion resistance, structural strength, and EMI shielding performance. Copper alloy contacts with gold plating ensure low contact resistance, consistent signal integrity, and extended mating durability. Rated at 3A and 5V, this USB-C receptacle delivers stable power and dependable connectivity for consumer electronics, industrial control systems, and embedded devices.
Designed for demanding environments, the connector features a waterproof structure, complies with UL94V-0 flame-retardant standards, and operates reliably within a temperature range of -40°C to +85°C. It offers a robust and cost-effective interconnect solution for USB-C 2.0 applications requiring durability and environmental protection.
Key Features
- USB-C 2.0 receptacle, single-port configuration
- 24-pin interface supporting up to 480 Mbps
- Right-angle PCB mount design
- Stainless steel shell with nickel plating
- Gold-plated copper alloy contacts
- Rated 3A, 5V, waterproof, UL94V-0, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C20-S-RA-CS52-WP-BK-TR | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right angle | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 3A | |
| Rated Voltage: | 5V |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB-C 2.0 Connector, Receptacle, 24 Pin, 480 Mbps:
USB 4.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
