Right Angle 8mm HVIL Automotive Connector, 2 Pin Plug, A Key, 50mm²
Introduction
The 8mm HVIL electric vehicle connector is a high-performance solution engineered specifically for demanding EV and battery applications. This straight-orientation Plug connector, utilizing a defined A Key configuration, ensures proper mating and error-proof installation in critical high-voltage pathways. Designed to accommodate substantial power, it features an 8mm terminal diameter and supports a 50mm² wire gauge with integrated shielding, essential for managing high current while mitigating EMI within compact spaces. The core HVIL (High Voltage Interlock Loop) safety mechanism is integrated across the two pins, guaranteeing that the safety circuit is broken before the main power contacts disengage, offering crucial protection for maintenance personnel and system integrity.
Constructed for maximum reliability under extreme conditions, the connector utilizes a rugged PA66-GF housing for superior mechanical and thermal performance. The contact components are crafted from high-conductivity Copper Alloy and finished with premium Silver Plating, ensuring minimal resistance and maximum lifespan under heavy load. Technically rated for 1500V DC and a formidable 250A, this 2-pin connector delivers exceptional power density. Its robust design is certified IP67 for protection against dust and temporary water immersion, UL94V-0 for flame retardancy, and boasts a broad operational temperature range of -40°C to 125°C, making it the definitive choice for next-generation EV power systems.
Key Features:
- Dual Pin HVIL Safety: 2 Pin configuration with integrated HVIL for enhanced safety protocol.
- High-Power Rating: Rated for 1500V DC and a 250A continuous current.
- Optimal Wire Handling: Supports 50mm² wire gauge with shielding; 8mm terminal diameter.
- Premium Material: PA66-GF housing and Silver Plated Copper Alloy contacts for reliability.
- Extreme Environment Ready: IP67 and UL94V-0 certified, operating from -40°C to 125°C.
Main Specifications:
General Information:
| Part No.: | ST516000-A-50 | |
| Product Series: | HVIL Connectors | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Right Angle | |
| Connector Coding: | A Key | |
| Number of Positions: | 2 Pin | |
| Terminal Diameter: | 8mm | |
| Wire Gauge: | 50mm² | |
| Shielding: | Shielded | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | PA66-GF | |
| Shell Plating: | Not Applicable | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Silver Plated |
Electrical Performance:
| Rated Voltage: | 1500V DC | |
| Rated Current: | 250A | |
| Insulation Resistance: | > 200MΩ | |
| Withstanding Voltage: | 3000V AC | |
| Durability (Mating): | < 500 Cycles |
Environmental Performance:
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C |
Applications of this Right Angle 8mm HVIL Automotive Connector:
HVIL (High Voltage Interlock Loop) connectors are critical safety-centric components designed to ensure that a high-voltage system is automatically and safely de-energized before a connection is fully broken..
Here are some main applications:
- Battery Pack Module Interconnects in Electric Vehicles;
- High-Voltage Cable Harness Termination Points;
- Inverter / Motor Controller Interfaces;
- Electric / Hybrid Vehicle Accessories (HV Loads);
- Power Distribution Units / Junction Boxes in EVs;
- On-board Chargers / DC Fast Charger Interfaces.
Factory pricing and exceptional product quality. Get a free quote now!
