High Voltage Interlock Loop 4 Pin EV Connector, Socket, A Key, 6mm², 40A

Introduction

This 4-pin straight socket connector is engineered for robust performance in electric vehicle high-voltage interlock loops (HVIL). Constructed with a PA66-GF material shell offering UL94V-0 flame resistance, it ensures superior protection in demanding environments. The copper alloy contacts, finished with a reliable tin plating, are designed for a 6mm² shielded wire, guaranteeing stable power transmission and signal integrity. Rated for 800V DC and 40A, this connector is built to handle the high-power demands of modern EV systems. Its IP67 rating provides complete protection against dust and temporary immersion, while the operating temperature range of -40°C to +125°C ensures consistent performance in extreme conditions. The integrated A-key polarization prevents mismating, enhancing safety and reliability.

Key Features:

  • 4-Pin Socket, A Key, Straight
  • Rated 800V DC / 40A
  • IP67 Protection Level
  • -40°C to +125°C Operating Temperature
  • 6mm² Wire Gauge with Shield
  • UL94V-0 Flame-Retardant Housing (PA66-GF)
  • Tin-Plated Copper Alloy Contacts

Main Specifications:

General Information:

Part No.: ST530000-A
Product Series: HVIL Connectors
Brand: Metabee
Gender: Socket
Orientation: Straight
Connector Coding:  A Key
Number of Positions:  4 Pin
Wire Gauge:  6mm²
Shielding:  Shielded
Other Feature: None

Materials and Plating:

Shell Material:  PA66-GF
Shell Plating:  Not Applicable
Contact Material:  Copper Alloy
Contact Plating:  Tin-Plated

Electrical Performance:

Rated Voltage:  800V DC
Rated Current: 40A
Insulation Resistance:  > 200MΩ
Withstanding Voltage: 3000V AC
Durability (Mating): < 500 Cycles

Environmental Performance:

IP Rating:  IP67
Flammability Rating:  UL94V-0
Operating Temperature:  -40°C to +125°C

Applications of this High Voltage Interlock Loop 4 Pin EV Connector:

HVIL (High Voltage Interlock Loop) connectors are critical safety-centric components designed to ensure that a high-voltage system is automatically and safely de-energized before a connection is fully broken..

Here are some main applications:

  • Battery Pack Module Interconnects in Electric Vehicles;
  • High-Voltage Cable Harness Termination Points;
  • Inverter / Motor Controller Interfaces;
  • Electric / Hybrid Vehicle Accessories (HV Loads);
  • Power Distribution Units / Junction Boxes in EVs;
  • On-board Chargers / DC Fast Charger Interfaces.

HVIL Connectors Application
