High Current HVIL A Key 5 Pin Plug Connector, 6mm², IP67
Introduction
This High Current HVIL (High Voltage Interlock Loop) connector is a 5-pin plug designed for robust and reliable performance in high-voltage applications. Engineered with an A Key configuration and a straight orientation, it ensures proper mating and secure connections. The connector features a PA66-GF housing for excellent mechanical strength and a UL94V-0 flame-retardant rating, while the tin-plated copper alloy contacts provide superior conductivity and corrosion resistance.
Built to withstand demanding environments, this shielded connector boasts an IP67 rating for complete protection against dust and water immersion. It is rated for 800V DC and 40A, with a wide operating temperature range of -40°C to 125°C. The 6mm² wire gauge is ideal for managing high-current flows, making it a perfect and safe choice for electric vehicle and industrial power systems.
Key Features:
- 5-Pin Plug, A Key
- High Current 40A & 800V DC
- 6mm² Wire Gauge with Shielding
- IP67 Rated (Dust & Waterproof)
- PA66-GF Housing, UL94V-0
- Tin-Plated Copper Alloy Contacts
- Operating Temperature: -40°C to +125°C
Main Specifications:
General Information:
| Part No.: | ST533000-A-6 | |
| Product Series: | HVIL Connectors | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 5 Pin | |
| Wire Gauge: | 6mm² | |
| Shielding: | Shielded | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | PA66-GF | |
| Shell Plating: | Not Applicable | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Tin-Plated |
Electrical Performance:
| Rated Voltage: | 800V DC | |
| Rated Current: | 40A | |
| Insulation Resistance: | > 200MΩ | |
| Withstanding Voltage: | 3000V AC | |
| Durability (Mating): | < 500 Cycles |
Environmental Performance:
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C |
Applications of this High Current HVIL A Key 5 Pin Plug Connector:
HVIL (High Voltage Interlock Loop) connectors are critical safety-centric components designed to ensure that a high-voltage system is automatically and safely de-energized before a connection is fully broken..
Here are some main applications:
- Battery Pack Module Interconnects in Electric Vehicles;
- High-Voltage Cable Harness Termination Points;
- Inverter / Motor Controller Interfaces;
- Electric / Hybrid Vehicle Accessories (HV Loads);
- Power Distribution Units / Junction Boxes in EVs;
- On-board Chargers / DC Fast Charger Interfaces.
Factory pricing and exceptional product quality. Get a free quote now!
