6mm High Voltage Interlock Loop 1 Pin Cable, Plug, A Key, 25mm², 125A
Introduction
The HVIL Cable is designed for advanced electric vehicle and high-voltage system applications, where reliable circuit interlocking and superior electrical performance are crucial. Featuring a straight plug design with a single-pin A-key configuration, this HVIL cable ensures secure mating and precise alignment to prevent misconnections during high-voltage operations.
Constructed with a zinc alloy housing for enhanced mechanical durability and nickel-plated copper alloy contacts for excellent conductivity and corrosion resistance, this cable guarantees long-term stability even in harsh automotive or industrial environments. The 25mm² wire gauge supports a continuous current rating of 125A and a voltage rating of 1000V, making it suitable for demanding high-power systems. Additionally, it complies with IP67 ingress protection and UL94V-0 flame retardancy, ensuring top-tier safety against dust, water, and fire. With an operating temperature range of -40°C to 125°C, this cable delivers reliable performance in extreme conditions.
Key Features:
- 1-pin straight plug with A-key design for secure, precise connection.
- Metal shell with nickel-plated copper contacts for superior conductivity.
- Rated at 1000V / 125A for high-power applications.
- 25mm² wire gauge with 0.5m cable length.
- IP6K9K protection and UL94V-0 flame-retardant rating.
- Wide operating temperature range from -40°C to 125°C.
Main Specifications:
General Information:
| Part No.: | NI1-1-S060-1AYN-C08-L0.5 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 1 Pin | |
| Wire Gauge: | 25mm² | |
| Cable length: | 50cm | |
| Shell Material: | Zinc Alloy | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 125A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 6 mm High Voltage Interlock Loop 1 Pin Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
