Introduction:
The 623K6 series is a 6P6C wired interface for professional telephone handset systems and data equipment. Successful performance is sustained across an extreme -40C to +125C industrial temperature range without signal degradation. Six pre-stripped and tinned 26 AWG UL 1061 wire leads facilitate quick electrical termination within various device enclosures. Robust medium gray ABS housing utilizes built-in panel stops to provide a secure mechanical bond during installation. Gold over nickel plating on phosphor bronze contacts strictly maintains electrical resistance below 20 miliohms. High insulation resistance exceeding 1000 Mohms ensures flawless audio clarity throughout the service life. These modular components are ideal for telecom handsets, security intercoms, and industrial control systems.
Key Features
- 6P6C RJ11 Configuration: Supports standard six-wire voice and data interfaces.
- Integrated Wire Leads: Pre-tinned 26 AWG leads simplify system assembly.
- Extreme Temperature Range: Operates reliably from -40C to +125C.
- Secure Panel Mounting: Medium gray housing includes built-in stops.
- Low Resistance Contacts: Gold-plated finish ensures integrity below 20 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJP-623-K6-X-A1-2 | |
| Series: | MTJP | |
| Category: | Modular Jacks with Wire Leads | |
| Product Type: | Jack | |
| Connector Type: | RJ11 | |
| Number of Positions/Contacts: | 6P6C | |
| Number of Ports: | 1×1 Port | |
| Model: | 623K6 | |
| Mounting Type: | Panel Stops | |
| Lead Termination: | Stripped and Tinned Wire | |
| Wire: | 26 AWG, UL 1061 | |
| Wire lenth: | Customized | |
| Shielding: | No Shielded |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 1000 Mohms Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Housing Material: | ABS | |
| Color: | Medium Gray | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated |
Environmental:
| Operating Temperature: | -40°C ~ +125°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
