Introduction:
The 616L model serves as a 4P4C telephone wired modular jack designed for reliable handset and telecom connectivity. Stripped and tinned 26 AWG UL 1061 PVC coated leads integrate into the component to simplify rapid board termination. Robust deep gray ABS housing incorporates built-in panel stops for secure right-angle alignment during installation. Gold over nickel plating on phosphor bronze contacts ensures signal integrity with insulation resistance exceeding 1000 Mohms. Consistent performance is maintained throughout the industrial -40C to +70C temperature range without signal loss. Intercom systems, telephone handsets, and office communication hubs frequently incorporate this versatile 4 wire phone jack.
Key Features
- 4P4C RJ9 Configuration: Facilitates standard four-wire telephone handset interfaces.
- UL 1061 Wired Leads: Stripped 26 AWG wires simplify system integration.
- Secure Panel Mounting: Deep gray ABS housing features built-in stops.
- High Insulation Resistance: Maintains 1000 Mohms Min for signal clarity.
- Industrial Temperature Range: Operates reliably from -40C up to +70C.
Main Specifications:
General Information:
| Product No.: | MTJP-616L-X-A1-2 | |
| Series: | MTJP | |
| Category: | Modular Jacks with Wire Leads | |
| Product Type: | Jack | |
| Connector Type: | RJ9 | |
| Number of Positions/Contacts: | 4P4C | |
| Number of Ports: | 1×1 Port | |
| Model: | 616L | |
| Mounting Type: | Panel Stops | |
| Lead Termination: | Stripped and Tinned Wire | |
| Wire: | 26 AWG, UL 1061, PVC Coated | |
| Wire lenth: | Customized | |
| Shielding: | No Shielded |
Electrical:
| Rated Voltage: | 150VAC | |
| Rated Current: | 1.5 Amp | |
| Contact Resistance: | N/A | |
| Insulation Resistance: | 1000 Mohms Min | |
| Dielectric withstanding voltage: | 1000 VAC for 1 minute |
Materials and Plating:
| Housing Material: | ABS | |
| Color: | Deep Gray | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated |
Environmental:
| Operating Temperature: | -40°C ~ +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
