3.6mm High Voltage Interlock Loop HVIL Connector Cable, 2 Pin Socket, A Key, 10mm², 50A
Introduction
This 3.6mm HVIL connector cable is engineered for safe and reliable connections in high-voltage automotive and industrial applications. Featuring a 2-pin Socket configuration in a Straight orientation with an A Key, it ensures proper mating and prevents mismating. The robust construction includes a PA66+GF housing for excellent mechanical strength and heat resistance, complemented by copper alloy contacts that are nickel-plated for superior conductivity and corrosion resistance. With a substantial 10mm² wire gauge and a 10cm cable length, it is built to handle significant power transmission.
Designed for demanding environments, this connector boasts an impressive IP67 rating, offering complete protection against dust and temporary immersion in water. It meets the stringent UL94V-0 flammability standard, ensuring it does not propagate flame. The component is rated for a high voltage of 1000V and a continuous current of 50A, with an operational temperature range from -40°C to +125°C, guaranteeing stable performance under extreme conditions. This makes it an ideal and secure choice for battery packs and high-voltage systems.
Key Features:
- 3.6mm HVIL 2-Pin Socket, A Key
- High 50A Current & 1000V Voltage Rating
- IP67 Rated for Dust and Water Resistance
- UL94V-0 Flame-Retardant Housing (PA66+GF)
- Wide Operating Temperature: -40°C to +125°C
- 10mm² Wire Gauge with Nickel-Plated Contacts
Main Specifications:
General Information:
| Part No.: | NI2-1-H036-2AYA-C06-L0.1 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Socket | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 2 Pin | |
| Shell Material: | PA66+GF | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 3.6mm | |
| Wire Gauge: | 10mm² | |
| Cable length: | 10cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 50A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 3.6mm High Voltage Interlock Loop HVIL Connector Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
