14mm Right Angle High Voltage Interlock Loop HVIL Cable, 1 Pin Plug, A Key, 150mm², 500A
Introduction
The 14mm HVIL cable is designed for high-current electric vehicle (EV) and industrial power distribution systems that require robust electrical safety and performance. Featuring a 1 Pin Plug with A Key configuration, it ensures precise alignment, secure locking, and reliable interlock protection to prevent accidental disconnection under high-voltage conditions.
Built with a Zinc Alloy housing and Nickel-Plated Copper Alloy contacts, this cable offers superior conductivity, corrosion resistance, and long-term durability in harsh operating environments. With a 14mm terminal diameter and 150mm² conductor, it supports a rated voltage of 1000V and a current capacity of 500A, enabling stable power transmission with minimal thermal rise. The IP67-rated sealing and UL94V-0 flame retardancy deliver excellent protection against water, dust, and fire, ensuring safe operation across a wide temperature range from -40°C to +125°C.
Key Features:
- 1000V/500A rated for high-power EV and industrial systems.
- Right Angle Plug with A Key design for secure, precise connection.
- 14mm terminal and 150mm² conductor for high-current transmission.
- Zinc Alloy shell with Nickel-Plated Copper contacts for strength and reliability.
- IP67 waterproof and UL94V-0 flame-retardant protection.
- Wide operating temperature range: -40°C to +125°C.
Main Specifications:
General Information:
| Part No.: | NI1-1-B140-1AYN-C15-L0.5 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Right Angle | |
| Connector Coding: | A Key | |
| Number of Positions: | 1 Pin | |
| Shell Material: | Zinc Alloy | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 14mm | |
| Wire Gauge: | 150mm² | |
| Cable length: | 50cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 500A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 14mm Right Angle High Voltage Interlock Loop HVIL Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
