14mm HV Hybrid Vehicle Electric Cable, 1 Pin Plug, A Key, 150mm², 500A
Introduction
Ensure robust power delivery and maximum safety in hybrid and electric vehicles with our 14mm HVIL hybrid vehicle electric plug cable. This high-performance component is designed as a 1-pin plug with a straight orientation and an A Key interface, guaranteeing simple, secure, and mistake-proof mating to prevent incorrect connections in critical high-voltage systems. Its construction features a durable zinc alloy shell and a nickel-plated copper alloy contact, providing superior corrosion resistance, excellent conductivity, and long-term mechanical reliability.
Engineered for the most demanding applications, this HVIL cable is built to withstand challenging operating conditions. It boasts a high 1000V/500A rating, supported by a substantial 150mm² wire gauge for efficient power transmission with minimal loss. The assembly is sealed to an IP67 rating, ensuring complete protection against dust and temporary water immersion. Furthermore, it complies with the UL94V-0 flame-retardant standard and operates reliably across a wide temperature spectrum from -40°C to +125°C, ensuring performance and safety in extreme environments.
Key Features:
- High 500A current rating with 150mm² wire gauge.
- 14mm terminal diameter and straight 1-pin plug design.
- A Key interface for secure, error-proof connections.
- IP67-rated for complete dust and water resistance.
- UL94V-0 flame-retardant material for enhanced safety.
- Wide operating temperature range (-40°C to +125°C).
Main Specifications:
General Information:
| Part No.: | NI1-1-S140-1AYN-C15-L0.5 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Straight | |
| Connector Coding: | A Key | |
| Number of Positions: | 1 Pin | |
| Shell Material: | Zinc Alloy | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 14mm | |
| Wire Gauge: | 150mm² | |
| Cable length: | 50cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 500A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 14mm HV Hybrid Vehicle Electric Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
