12mm High Voltage Interlock Loop HVIL Single Pole Cable, Plug, A Key, 120mm², 400A, Right Angle
Introduction
The 12mm HVIL cable is engineered for advanced electric vehicle (EV) and high-voltage power systems that demand superior safety and performance. Featuring a Right Angle Plug design with A Key orientation, this 1-pin connector ensures secure mating and reliable interlock functionality to prevent high-voltage exposure during disconnection.
Constructed with a Zinc Alloy shell and Nickel-Plated Copper Alloy contacts, the cable delivers exceptional conductivity, corrosion resistance, and mechanical durability under extreme operating conditions. Rated at 1000V and 400A, and equipped with a 12mm terminal diameter and 120mm² wire gauge, it ensures stable power transmission with minimal loss. The IP67 sealing and UL94V-0 flame retardancy make it ideal for harsh automotive and industrial environments. Operating efficiently between -40°C and +125°C, it maintains reliable performance even in demanding thermal cycles.
Key Features:
- Rated voltage 1000V and current 400A for high-power systems.
- Right Angle Plug with A Key design for secure connection.
- 12mm terminal and 120mm² conductor for optimized conductivity.
- Zinc Alloy shell with Nickel-Plated Copper contacts for durability.
- IP67 waterproof and UL94V-0 flame-retardant protection.
- Wide operating temperature range: -40°C to +125°C.
Main Specifications:
General Information:
| Part No.: | NI1-1-B120-1AYN-C14-L0.5 | |
| Product Series: | HVIL Cables | |
| Brand: | Metabee | |
| Gender: | Plug | |
| Orientation: | Right Angle | |
| Connector Coding: | A Key | |
| Number of Positions: | 1 Pin | |
| Shell Material: | Zinc Alloy | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Nickel-Plated | |
| Terminal Diameter: | 12mm | |
| Wire Gauge: | 120mm² | |
| Cable length: | 50cm | |
| Rated Voltage: | 1000 V | |
| Rated Current: | 400A | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +125°C | |
| Other Feature: | None |
Applications of this 12mm High Voltage Interlock Loop HVIL Single Pole Cable:
HVIL (High Voltage Interlock Loop) cables and their associated systems are crucial safety mechanisms primarily used in high-voltage applications to prevent electric shock and damage from arcing.
Here are some main applications:
- Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs);
- Inverter/motor drive interface;
- On-board charger (OBC) connection;
- Power distribution unit (PDU) / junction box systems;
- Stationary energy storage systems (ESS);
- Off-highway and heavy-duty electric equipment;
- DC fast-charging infrastructure;
- High-voltage thermal management systems.
Factory pricing and exceptional product quality. Get a free quote now!
