900 MHz LTE/GSM RFID Panel Antenna with RG316 Cable, 6dBi, SMA Male, IP66
Introduction:
Maximize your network efficiency with this high-performance 900 MHz LTE/GSM RFID panel antenna. Engineered for durability, this 6dBi gain antenna ensures consistent signal transmission in challenging environments. Its robust IP66-rated ABS radome protects against harsh weather, while the DC grounding provides essential lightning protection, making it an ideal solution for critical communication infrastructure.
Designed for seamless integration, this antenna features a versatile SMA Male connector with a flexible RG316 coaxial cable. With an operating temperature range of -40 °C to 85 °C and wind survivability up to 36.9 m/s, it delivers reliable, long-term performance for both indoor and outdoor industrial applications.
Key Features
- Frequency: 840–960 MHz optimized for LTE/GSM/RFID.
- High Gain: 6dBi performance with stable signal coverage.
- Robust Build: IP66-rated ABS housing for extreme weather.
- Engineered Reliability: VSWR ≤1.92 with DC Grounding protection.
- Versatile Connectivity: SMA Male connector with RG316 cable.
- Industrial Ready: Withstands -40 °C to 85 °C and high winds.
General Information:
| Product No.: | YC-KS50013 | |
| Connector Series: | Panel Antennas | |
| Brand: | Metabee | |
| Connector Type: | SMA Male or Customized | |
| Connector Orientation: | Straight | |
| Radome Material: | ABS | |
| Dimensions: | 258*258*33.5mm | |
| Color: | White | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 840-960 MHz | |
| Gain: | 6dBi | |
| VSWR: | ≤1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Environmental Performance:
| IP Rating: | IP66 | |
| Wind Survivability: | 36.9 m/s | |
| Lightning Protection: | DC Grounding | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this 900 MHz LTE/GSM RFID Panel Antenna:
Panel antennas are a type of directional antenna designed with a flat-panel structure that focuses RF energy into a specific coverage area. It is widely used in wireless communication systems.
Here are some key applications:
- WiFi access points
- 4G/5G communication systems
- GPS/GNSS equipment
- RFID systems
- Wireless surveillance
- Industrial automation
- Smart transportation
- Point-to-point bridges
- IoT gateways
- Marine communication systems
