Introduction:
The HM-Q2 is a shielded module from the HM series, specifically designed for high electromagnetic interference (EMI) environments. It features a full metal housing that provides 360° shielding for its two internal contacts, effectively protecting against external electric and magnetic fields to ensure the integrity and stability of sensitive signal transmission. Rated for 50V/10A and utilizing efficient crimp terminals, this module can be freely combined with other HM modules, making it the ideal choice for protecting critical signals in applications like VFDs, servo drives, and bus communications.
Key Feature:
- Crimp Terminal: The crimp terminal is a fast and robust solderless technology, characterized by its high mechanical strength and low contact resistance at the joint.
- Dedicated 2-Pin Configuration: Ideal for shielded twisted-pair applications, such as CAN bus, RS-485 communications, or sensor signal lines that require noise immunity.
- Modular Design: Can be freely combined with signal, data, and other modules in the same frame for highly customized connection solutions.
- 50V/10A Rating: Capable of safely transmitting sensitive control signals or providing a shielded power supply for small devices.
Main Specifications:
General Information:
| Product No.: | HM-Q2-M, HM-Q2-F | |
| Category: | Heavy-Duty Connector Inserts and Modules | |
| Connector Product Type: | Modules | |
| Connector Series: | HM Series | |
| Termination methods: | Crimp Terminal | |
| Number of Contacts: | 2 | |
| Wire Gauge: | 0.14-2.5 mm² |
Materials and Plating:
| Insert Material: | Polycarbonate | |
| Contact Material: | N/A | |
| Sealing Material: | N/A |
Electrical Performance:
| Rated Current: | 10A | |
| Rated Voltage: | 50V AC | |
| Contact Resistance: | ≤ 1 mΩ |
Environmental Performance:
| Temperature Range: | -40℃ to +125℃ | |
| Pollution degree: | 3 | |
| Flammability Rating: | UL94 V-0 |
Structure of Heavy-Duty Connectors
8 Series of Heavy-Duty Connector Inserts
Heavy-duty connector insert structure diagram (example)
Type of Example Image: HA-016-M/F
