D-sub HD26 Male Right Angle Connector for PCB Mount, Through Hole, Machined Contacts, 2.29mm Pitch

D-sub HD26 Male Right Angle Connector for PCB Mount, Through Hole, Machined Contacts, 2.29mm Pitch

Introduction:

This D-sub HD26 male right angle connector provides a high-density solution for complex I/O applications. It is engineered for direct PCB mounting, featuring through-hole solder pins for a highly stable and permanent bond to the circuit board. This connector is built with high-quality machined contacts, offering superior durability and a more reliable connection than standard stamped types. Its gold-plated contacts ensure excellent signal integrity across all 26 pins. With a rugged steel shell for protection, it’s an ideal choice for medical devices, industrial control systems, and specialized data communication equipment.

This D-sub HD26 right angle connector has many great features, including:

• High-Density: Offers a compact solution for applications requiring a high number of signal lines.
• Right Angle Orientation: Provides a space-saving, low-profile horizontal connection.
• Solder Termination: Forms a permanent electrical bond between the connector and the PCB.
• Machined Contacts: Provides superior durability and a more reliable connection for critical, high-mating-cycle use.
• Gold-Plated Contacts: Ensures excellent conductivity and long-term corrosion resistance across all pins.
• Durable Steel Shell: A strong nickel-plated housing offers robust physical protection and EMI shielding.

Main Specifications:

General Information:

Materials and Plating:

Electrical Performance:

Environmental Performance:

Applications of this D-sub HD26 right angle connector:

• Industrial Automation;
• Data Acquisition (DAQ) Systems;
• Test & Measurement Equipment;
• Medical and Laboratory Devices;
• Telecommunications & Networking;
• Legacy Computer Interfaces;
• Aviation and Marine Electronics;

Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
