Waterproof 17 Pin D-Sub 17W2 Female Combo Connector, Coaxial and Signal, Cable Type, IP67
Introduction:
This is a 17W2 hybrid D-Sub connector with a B-size shell. The Combo D-Sub combines both Coaxial contacts and Signal contacts in a single connector. 17W2 has two power contacts and 15 standard signal contacts. Achieves IP67 waterproof rating. Protects against dust and water immersion. Ensures reliability in harsh conditions. Features straight cable mount orientation. Solder cup termination enables secure cable attachment. The connector utilizes precision-machined contacts to guarantee high power transmission. Gold-plated brass contacts ensure superior conductivity. Operates reliably from -55°C to 125°C. Handles up to 40A current and 500V. Built for industrial power needs.
This waterproof 17W2 combo D-sub connector has many great features, including:
- IP67 Waterproof: Provides complete protection against water and dust, ensuring reliability in harsh environments.
- Solder Cup Termination: Allows for fast, secure, and reliable cable soldering.
- Precision Machined Contacts: Gold-plated brass contacts offer superior conductivity and long-term corrosion resistance.
- Wide Operating Temperature: Reliable performance in extreme conditions, from -55°C to +125°C.
- High Power Rating: Supports currents up to 40 amps and voltages up to 500 volts.
Main Specifications:
General Information:
| Product Number: | YC-681-5007 | |
| Connector Series: | Combo D-Sub | |
| Contact Arrangement: | 17W2 | |
| Orientation: | Straight | |
| Connector Gender: | Female | |
| Number of Contacts: | 17 Pin | |
| Shell Sizes: | B | |
| Mount Type: | Cable Mount | |
| Mount Feature: | Not Applicable | |
| Contact Termination: | Solder Cup | |
| Contact Type: | Machined Contacts | |
| Contact Function: | Coaxial and Signal |
Materials and Plating:
| Shell Material: | Steel | |
| Shell Plating: | Nickel Plating | |
| Contact Material: | Brass | |
| Contact Plating: | Gold Plating | |
| Contact Plating Thickness: | 3.00µin（0.076µm） | |
| Insulator Material: | Thermoplastic Polyester |
Electrical Performance:
| Current rating: | 10A/20A/30A/40A | |
| Rated Voltage: | 500V AC |
Environmental Performance:
| Temperature Range: | -55℃ to +125℃ | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94 V-0 |
Applications of the Waterproof 17W2 Combo D-Sub Connector:
- Mobile Robotics and AGV;
- Professional A/V and Stage Lighting;
- Medical Equipment Carts;
- Industrial Power Supplies and DC Motor Drives;
- Industrial Lasers and Plasma Cutting Systems;
- High-Power Test and Measurement.
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
