D-Sub DB9 Female Connector, Cable Mount, Solder Cup, Zinc Alloy Shell, 2.77mm Pitch, IP20
Introduction:
This D-sub DB9 female connector is designed for creating custom cable assemblies. It features easy-to-use solder cups, allowing you to make a secure and permanent connection by directly soldering your wires. Its housing is constructed from robust zinc alloy, which offers excellent durability and EMI shielding for signal integrity. The contacts are tin-plated for reliable performance and easy soldering. With an IP20 rating and a UL94 V-0 flame-retardant insulator, this connector is a safe and dependable choice for your projects.
Engineered for both safety and easy integration, this D-sub DB9 female connector includes the following key features:
- Solder Cup Termination: Enables direct and permanent soldering of wires for a highly reliable link.
- Cable Mount Design: Gives you the flexibility to build cables to the precise length your project requires.
- Zinc Alloy Shell: Provides superior durability and EMI shielding in a robust, die-cast housing.
- Tin-Plated Contacts: Offers good solderability and corrosion resistance for standard applications.
- IP20 Rating: Provides touch-proof protection, making it safe for use within indoor equipment.
Main Specifications:
General Information:
| Product No.: | YC-681-4062 | |
| Connector Series: | D-Sub Connectors | |
| Orientation: | Straight | |
| Connector Gender: | Female | |
| Number of Contacts: | 9 Pin | |
| Number of Rows: | 2 | |
| Pitch: | 2.77 mm | |
| Shell Sizes: | E | |
| Mount Type: | Cable Mount | |
| Mount Feature: | Through Hole | |
| Contact Termination: | Solder Cup | |
| Contact Type: | Stamped Contact | |
| Contact Function: | Signal |
Materials and Plating:
| Shell Material: | Zinc Alloy | |
| Shell Plating: | Nickel Plating | |
| Contact Material: | Brass | |
| Contact Plating: | Tin Plating | |
| Contact Plating Thickness: | 3.00 µin (0.076 µm) | |
| Insulator Material: | Thermoplastic Polyester |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | 500V AC | |
| Contact Resistance: | ≤ 20 mΩ |
Environmental Performance:
| Temperature Range: | -55℃ to +105℃ | |
| IP Rating: | IP20 | |
| Flammability Rating: | UL94 V-0 |
Applications of this D-sub DB9 female connector:
- Industrial Automation;
- Serial Communication;
- Telecommunications;
- Test & Measurement Equipment;
- Computer Peripherals;
- Robotics and CNC Machine Control;
- Prototyping and Custom Assemblies;
- Medical and Laboratory Equipment;
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
