D-Sub 9 Pin Female Connector, Cable Mount, Solder Cup, 2.77mm Pitch
Introduction:
This D-sub 9 pin female is designed for creating custom cable assemblies. It features easy-to-use solder cups, allowing you to make a secure and permanent connection by directly soldering your wires. A strong steel shell offers good physical protection for the terminals. The contacts are tin-plated for reliable performance and easy soldering. With an IP20 rating and a UL94 V-0 flame-retardant insulator, this connector is a safe and dependable choice for your projects.
Engineered for both safety and easy integration, this D-sub 9 pin female connector includes the following key features:
- Solder Cup Termination: Enables direct and permanent soldering of wires for a highly reliable link.
- Cable Mount Design: Gives you the flexibility to build cables to the precise length your project requires.
- High Power Capability: Rated for 5A current and 500V voltage, making it suitable for both signal and power applications.
- Durable Construction: A strong steel shell with nickel plating offers excellent protection against physical damage and corrosion.
- IP20 Rating: Provides touch-proof protection, making it safe for use within indoor equipment.
Main Specifications:
General Information:
| Product No.: | YC-681-4013 | |
| Connector Series: | D-Sub Connectors | |
| Orientation: | Straight | |
| Connector Gender: | Female | |
| Number of Contacts: | 9 Pin | |
| Number of Rows: | 2 | |
| Pitch: | 2.77 mm | |
| Shell Sizes: | E | |
| Mount Type: | Cable Mount | |
| Mount Feature: | Through Hole | |
| Contact Termination: | Solder Cup | |
| Contact Type: | Stamped Contact | |
| Contact Function: | Signal |
Materials and Plating:
| Shell Material: | Steel | |
| Shell Plating: | Nickel Plating | |
| Contact Material: | Brass | |
| Contact Plating: | Tin Plating | |
| Contact Plating Thickness: | 3.00 µin (0.076 µm) | |
| Insulator Material: | Thermoplastic Polyester |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | 500V AC | |
| Contact Resistance: | ≤ 20 mΩ |
Environmental Performance:
| Temperature Range: | -55℃ to +105℃ | |
| IP Rating: | IP20 | |
| Flammability Rating: | UL94 V-0 |
Applications of this D-sub 9 pin female connector:
- Industrial Automation;
- Serial Communication;
- Telecommunications;
- Test & Measurement Equipment;
- Computer Peripherals;
- Robotics and CNC Machine Control;
- Prototyping and Custom Assemblies;
- Medical and Laboratory Equipment;
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
