Right Angle 9 Pin D-Sub Male Connector, PCB Mount, Through Hole, 2.77mm Pitch, 4-40 UNC Screw Lock

Right Angle 9 Pin D-Sub Male Connector, PCB Mount, Through Hole, 2.77mm Pitch, 4-40 UNC Screw Lock

Introduction:

This right angle 9 pin D-sub male connector is engineered for maximum stability. Its right angle profile is ideal for space-constrained layouts. It is designed with a long mounting bracket that provides exceptional mechanical support, reducing stress on the solder joints. The connector uses through-hole technology, and its pins are soldered for a permanent bond. Integrated 4-40 UNC screw locks secure the mating connector, preventing accidental disconnections in high-vibration environments. With gold-plated contacts for superior signal integrity, it’s an excellent choice for robust industrial applications.

This right angle 9 pin d sub male connector has many great features, including:

• Right Angle Orientation: Provides a space-saving, low-profile horizontal connection.
• Solder Termination: Forms a permanent electrical bond between the connector and the PCB.
• Long Bracket Support: Provides extra mechanical stability and reduces physical stress on the solder joints.
• 4-40 UNC Screw Lock: Locks the mating connector in place, preventing disconnections from vibration or pull.
• Gold-Plated Contacts: Delivers superior signal integrity and long-term corrosion resistance.
• Durable Steel Shell: Offers robust physical protection for the connection point.

Main Specifications:

General Information:

Materials and Plating:

Electrical Performance:

Environmental Performance:

Applications of this right angle 9 pin D-sub male connector:

• Industrial Automation;
• Serial Communication;
• Telecommunications;
• Test & Measurement Equipment;
• Computer Peripherals;
• Robotics and CNC Machine Control;
• Prototyping and Custom Assemblies;
• Medical and Laboratory Equipment;

Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
