Waterproof High Density D-Sub 15-Pin Male Connector, Cable Type, Machined Contacts, 2.29mm Pitch, IP67
Introduction:
This Waterproof HD15 male Connector delivers robust performance. Achieve secure cable integration with its IP67-rated steel housing. Resist water, dust, and corrosion effectively. Benefit from high-density 15-pin contacts in a compact 3-row layout. Precision-machined brass contacts offer superior conductivity. Gold plating over nickel ensures optimal signal integrity and corrosion resistance. The straight orientation simplifies cable routing. Solder cup termination provides a strong, reliable wire bond. The PBT insulator maintains stability across a wide temperature range. Withstand temperatures from -25°C to +85°C. Rated for 5A and 250V. Ensure reliable signal connections in harsh environments. Built for demanding industrial, marine, and outdoor applications requiring dependable, sealed connections.
Main Features:
- High-Density HD15 Interface: Features 15 male signal pins arranged in 3 rows.
- IP67 Sealed Design: Guarantees waterproof and dustproof performance.
- Cable Mount Style: Designed for direct and secure attachment to cable ends.
- Solder Cup Termination: Ensures reliable, robust electrical connections to wires.
- Precision 2.29mm Pitch: Enables compact design for space-constrained applications.
- Wide Operating Temperature: Functions reliably from -25°C to +85°C.
Main Specifications:
General Information:
| Product Number: | YC-681-5023 | |
| Connector Series: | High Density D-Sub | |
| Orientation: | Straight | |
| Connector Gender: | Male | |
| Number of Contacts: | 15 Pin | |
| Number of Rows: | 3 | |
| Pitch: | 2.29mm | |
| Shell Sizes: | A | |
| Mount Type: | Cable Type | |
| Contact Termination: | Solder Cup | |
| Contact Type: | Machined Contacts | |
| Contact Function: | Signal |
Materials and Plating:
| Shell Material: | Steel | |
| Shell Plating: | Nickel Plating | |
| Contact Material: | Brass | |
| Contact Plating: | Gold Plating | |
| Contact Plating Thickness: | 3.00µin（0.076µm） | |
| Insulator Material: | PBT |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | 250V AC | |
| Contact Resistance: | ≤ 10 mΩ |
Environmental Performance:
| Temperature Range: | -25℃ to +85℃ | |
| IP Rating: | IP67 | |
| Flammability Rating: | UL94 V-0 |
Applications of the Waterproof High Density D-Sub 15 Pin Male Connector:
- Industrial Control Systems
- Marine Electronics & Navigation
- Medical Monitoring Devices
- Outdoor LED Displays & Signage
- Test & Measurement Systems
- Transportation Telematics
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
